Sales Code: 521-715

TOUCHLOCK keypad – Vandal resistant, metal



excl. VAT

Use with Switch2 or Net2
Vandal resistant design
Robust metal construction
Security fixing screws
Backlit keypad
IPX7 rated - suitable for external use

About – The vandal resistant metal keypad is for use with Switch2 and Net2 systems. The keypad is manufactured using a cast metal housing and is supplied with a choice of a metal mounting plate or a metal surface mounting box. This robust keypad is also backlit for ease of use in low lighting conditions.

Installation – The keypad is wired as shown on the control unit label. The cable exits centrally from the back of the keypad. A metal mounting plate is provided to give a secure fixing to the mounting surface. Alternatively a surface mounted back box is provided to allow the cable to be terminated at the keypad. The keypad is attached to the mounting plate using four large security fixings. A security tool is provided.

Operation – A code is entered using the keypad. The control unit checks the validity of the code and grants or denies access as appropriate.
